Braided Hose Pipe
High-Pressure Synthetic Yarn Reinforced Polymer Hose
Engineered for Durability & Flex Life
Engineered for high-pressure fluid, compressed air, and chemical conveyance, J-TEX POLYMERS Braided Pipes feature a multi-layer design with high-tenacity synthetic polyester yarn braiding sandwiched between inner and outer crystal-clear PVC layers. This structure prevents burst under pressure while offering high transparency, oil resistance, and non-kinking flexibility.
Key Product Features
Braided Hose Pipe Specifications
| Inner Size (mm) | Wall Thickness (mm) | Working Press. (kg/cm²) | Std. Coil Length (mtr) |
|---|---|---|---|
| 5 / 6 / 8 mm | 2.5 - 3.0 mm | 25 kg/cm² | 50 / 100 mtr |
| 10 / 12 / 15 mm | 3.5 mm | 20 - 25 kg/cm² | 50 / 100 mtr |
| 20 mm | 4.0 mm | 20 kg/cm² | 100 / 200 mtr |
| 25 / 31 mm | 4.8 mm | 15 kg/cm² | 50 / 100 mtr |
| 40 / 50 mm | 5.0 - 6.0 mm | 7 - 10 kg/cm² | 30 / 50 mtr |
Recommended Applications
Pneumatic Tools & Air Lines
Air supply hose lines for workshop tools, pneumatic machinery, and assembly lines.
High-Pressure Water Transfer
Commercial washdown, high-pressure car cleaning, and industrial equipment rinsing.
Gas & Fluid Lines
Piping lines for non-corrosive liquids, liquid pesticides, and factory process water.
Domestic High-Pressure Hose
Heavy-duty outdoor hose replacement for demanding residential water lines.
Need a Product Quote for Braided Hose Pipe?
Contact J-TEX POLYMERS sales engineers for coil pricing, minimum order quantities, and custom compounds.
